CKG35S Flat Bed CNC Lathe
CKG35S Flat Bed CNC Lathe, horizontal gang type liner rail CNC lathe, with CE ISO certificate
Send InquiryProduct Detail
Product Description
CKG35S is a linear guide way lathe which is designed for turning stainless steel products;
Mono-block design of base body, improve the rigidity of machine tool; X axis and Z axis ball screw adopt the prestretching structure to reduce the impact of thermal deformation on cutting;
The spindle bearing adopts angular contact ball bearing with three pairs in front and two pairs for rear part to ensure the high rigidity and durable accuracy of spindle;
The large slide adopts box structure and lightweight design to reduce the inertia and improve the acceleration of slide assembly;
Automatic centralized lubrication device, lubrication is fully reliable;
The cooling and chip removal system uses a floor-separated water tank and an iron chip box (the side and rear chip removal devices can also be selected), which is convenient for cleaning.
Product Parameter
Item | CKG35S |
Swing diameter over bed | Φ320 mm |
Swing diameter over slide | Φ110 mm |
X/Z axis travel | 300/280 mm |
Bar through hole | Φ35 mm |
Spindle speed | 4000 r/min |
X/Z axis rapid travel speed | 18/18 m/min |
X/Z servo motor torque | 6/6 N.m |
Clamping | Pneumatic |
Tools | Gang type tool post |
Tool shank dimension | 20*20 mm |
Boring tool size | Φ20 mm |
Chuck size | Collet/6 inch chuck |
Repeatability accuracy X/Z axis | 0.004/0.005 mm |
Tailstock quill diameter | / |
Tailstock quill travel | / |
Tailstock quill taper | / |
Total power consumption | 7.68 KVA |
Overall dimensions(L*W*H) | 1670*1450*1620 mm |
Weight | 1850 kg |
